RTV116 - RED (350gm Tube)
GIS9318
Momentive SNAPSIL™ RTV116 (Red) – High-Temperature Self-Leveling Silicone Sealant
SNAPSIL™ RTV116 is a one-component, red, self-leveling silicone sealant engineered for high-temperature applications requiring excellent flow into tight spaces and surface voids. It cures at room temperature upon exposure to atmospheric moisture, forming a flexible, resilient silicone rubber that maintains performance under extreme thermal conditions. RTV116 is ideal for thin-section potting, protective coatings, and electrical insulation where high-temperature resistance and self-leveling properties are essential. Like other acetoxy-cure silicones, it releases acetic acid during cure and is not recommended for use with acid-sensitive metals.
Key Features
- High-temperature performance: Continuous use up to 260°C (500°F); intermittent exposure up to 315°C (600°F)
- Self-leveling consistency – Flows easily into small crevices, gaps, and hard-to-reach areas
- Room-temperature moisture cure – No mixing, heat, or primers required for most substrates
- Excellent adhesion to metals, glass, ceramics, and many plastics
- Superior electrical insulation – Suitable for high-temp electrical and electronic applications
- Good weatherability and chemical resistance – Resists ozone, aging, and many industrial fluids
Typical Applications
- Thin-section potting and encapsulation
- Filling surface voids and micro-gaps in high-temp assemblies
- Self-leveling protective coatings for electrical components
- High-temperature gasketing where flowability is required
Certifications & Compliance
- UL Recognized (File No. E-36952)
- FDA Compliant: Meets 21 CFR 177.2600 for repeated food contact
- USDA Approved for use in meat and poultry processing equipment
- NSF/ANSI Standard 51 Certified for food equipment applications
- Military Specification Approved: MIL-A-46106, Group III, Type II – High Temperature Flowable
Technical Notes
- Maximum recommended cure thickness: 6 mm (¼ inch)
- Releases acetic acid during cure—avoid use with copper, brass, or other acid-sensitive metals
- Tack-free time: ~30 minutes at 25°C (77°F) and 50% RH
- Full cure (3 mm thickness): ~24 hours under standard conditions
- Shore A hardness: 20 (softer than paste variants for better conformability)
- Tensile strength: 25 kg/cm² (350 psi)
- Elongation: 350%
- Dielectric strength: 16 kV/mm (400 V/mil)
Packaging Options
- Available in cartridges and tubes
